Product Detail

Name: HA415 Amp - Goldensound
Brand: Supplier

Home » Product » ACXAUDIO » Amplifier » HA415 Amp

HA415 Amp

Simple, discrete, and effective. The HA series is an series of PoE++ / DSP / Dante + Amplifiers that are designed to allow users to setup multiple speakers in up to 4 speakers in one, or multiple rooms at a time.
The HA series are compact, weighing only around 1.5lbs with Dual Channel 30w, or Four Channel output while supporting Dnate/AES67 Network Audio. Each channel can control audio, mute, and input matrix.
Paired with ACXConsole the HA series lets users monitor the status of the speakers and connection ports to quickly identify any issues and make setup a breeze, all while barely taking up any space in a room as if it was never there.

Share This Items :

The HA series is a PoE++ Power amplifier with Dante/AES67. The HA230 and HA415 has 2x30 and 4x15w output respectively. The device has a High Pass Filter that can be configurated by the user, 8GEQ, Limiter, Phase, LED Level display, and 1khZ of pink noise. The system has an auto/manual detection within 5 seconds and a 4ohms / 8ohm/s loading auto detect.

Being a PoE amplifier means the device only needs to use CAT-X, drastically simplifying the setup for users in settings such as schools, businesses, government institutions, and other indoor or small locations. Combined with its Dante functionality and being AES67 compatible makes it ideal for technicians as they only need a single ethernet cable to power an entire audio system.

The tiny size of 25x191.192mm means it is small enough to be fitted onto CLS series of speakers, and being cooled through convection makes it also completely silent.

Electrical

Power-over-Ethernet

PoE++ to IEEE 802.3bt, Class 4

Power Consumption

90W maximum

Power Output

Four (4) channel, 15W/channel maximum

Operating Temperature

32-104⁰F (0-40⁰C)

Cooling

Convection cooling, no fan

Humidity

0-95% relative humidity, non-condensing

Connectivity

LAN: (1) RJ45, PoE++ powered;
Speaker(s): (4) RJ45, amplified audio out

Audio Networking

Dante™ with AES67-compliance, four (4) output channels

Amplifier Type

Class D

Amplifier Power

Four channel: 15W

Frequency Response (20Hz-20kHz)

+/- 1dB

Sample Rate

48kHz

Dynamic Range (20Hz-20kHz BW)

>90dB

THD+N (20Hz to 22kHz)

<0.3%

Intermodulation Distortion (SMPTE)

<0.3%

Crosstalk (Channel-to-Channel at 1kHz)

<-90dB

Controls, Service & Indicators
Mechanical

Reset: Momentary tactile button;
Status: RGB LED indicator;
LAN (PoE++)/LAN RJ45 indicators: Green (left) - Link Status, On = Link Established;
Off = No Link; Green (right) - Blink on data activity;

Finish

Matt black with ruggedized coating; labels in white

Weight

1.5kg / 0.7lbs

Dimensions (HxWxD)

1.12″ x 7.83″ x 4.49″ (28.5 x 199 x 114 mm)

Mounting

mounts onto any flat surface

Electrical

Power-over-Ethernet

PoE++ to IEEE 802.3bt, Class 4

Power Consumption

90W maximum

Power Output

Four (4) channel, 15W/channel maximum

Operating Temperature

32-104⁰F (0-40⁰C)

Cooling

Convection cooling, no fan

Humidity

0-95% relative humidity, non-condensing

Connectivity

LAN: (1) RJ45, PoE++ powered;
Speaker(s): (4) RJ45, amplified audio out

Audio Networking

Dante™ with AES67-compliance, four (4) output channels

Amplifier Type

Class D

Amplifier Power

Four channel: 15W

Frequency Response (20Hz-20kHz)

+/- 1dB

Sample Rate

48kHz

Dynamic Range (20Hz-20kHz BW)

>90dB

THD+N (20Hz to 22kHz)

<0.3%

Intermodulation Distortion (SMPTE)

<0.3%

Crosstalk (Channel-to-Channel at 1kHz)

<-90dB

Controls, Service & Indicators
Mechanical

Reset: Momentary tactile button;
Status: RGB LED indicator;
LAN (PoE++)/LAN RJ45 indicators: Green (left) - Link Status, On = Link Established;
Off = No Link; Green (right) - Blink on data activity;

Finish

Matt black with ruggedized coating; labels in white

Weight

1.5kg / 0.7lbs

Dimensions (HxWxD)

1.12″ x 7.83″ x 4.49″ (28.5 x 199 x 114 mm)

Mounting

mounts onto any flat surface
